MODEL	AMI 150-12	AMI 300-12	AMI 600-12
Wave Form	Pure sine wave
OUTPUT
AC Voltage	100/110/115/120Vac or 200/220/230/240Vac
Continuous Power	150W	300W	600W
Surge Power	300W	600W	1200W
Frequency	50Hz / 60Hz ± 5 %		50Hz / 60Hz ± 1 %
AC Regulation	± 5 %		± 3 %
Efficiency	> 84 %	> 84 %	> 86 %
INPUT
DC Current(without load)	0.5A	0.7A	0.4A
DC Current	16A	35A	61A
Over Load	> 120 % : 4 seconds
Short Circuit Protection	Electronic circuit  > 300%		Electronic circuit  > 300%
Battery Voltage Range	10.5V ~ 15.0V
Battery Low Voltage Shutdown	10.5V ± 5 %
Battery Low Voltage Return	12.8V ± 5 %
Battery Hi Voltage Shutdown	15.0V ± 5 %
Battery Hi Voltage Return	14.3V ± 5 %
Battery Polarity Reverse	Fuse burn out
LED  Indicator	Normal (Green), Fault (Red)
ENVIRONMENT
Over Temperature	60 ℃  ± 5 ℃
Operation Temperature	0-40 ℃(32-104 ℉)
Relative Humidity	0-95% (non-condensing)
Audible Noise(At 1M)	< 55dBA
PHYSICAL
Dimensions(W*D*H)mm	96.3*137*53	96.3*162*53	131.5*260*65
Net Weight(Kg)	0.73	0.87	1.6
✽ All specifications mentioned above are sujbect to change without prior notice
